FEATURES

Coupler Type

2 5/16" Ball Coupler

Frame Construction

Fully Integrated, All Tube, Roof and Sidewall Design

        • 24” OC Floor Crossmembers

        • 16” OC Wall Posts

        • 24” OC Roof Framing

Length 12', 14' and 16'

Width 7'6"

Axles Tandem 7000# GVWR

Floor Rubber RTP Flooring, Ramp Deck and Extension

Rear Door Ramp Door: 81 3/4" wide

Side Door 32" Aluminum Framed Side Door with Flush Lock

Ramp Standard

Tie Downs 5000# D-Ring Tie-Downs (8)

Color Options Yes

Warranty 6-Year Limited Warranty

Truck'n America strives to ensure the accuracy of information presented on this site. However there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.

Tires:

Radial

ST205/75R15

Load Range C

Features:

Aluminum Tube Perimeter Frame

V-Nose Front with Slope

Low Profile Design for Easy Loading/Unloading

18” Beavertail

Drop-Down Cornerpost Jacks

Silver Aluminum Wheels

White Vinyl Sidewalls & Ceiling

ABS Sidewall Vents (pr.)

Removable Wheel Chocks (2)

Aluminum Transition Flap Over Hinge

.030 Bonded (Screwless) Exterior

Wide Extruded Aluminum Top/Bottom Trim for Bold Appearance

Innovative “Overlock” Aluminum Roof Design is Screwless and Seamless

Spring-Assisted Rear Ramp Door with 16” Flap (3000# rated)

24” ATP Stoneguard

LED Lighting

6-Year Limited Warranty
