FEATURES

Coupler Type 2 5/16" - 10,000lb

Configuration of Front / Roof 6' Long V-Nose/Flat Top

Length 18 - 30ft

Width 7ft

Axles

Quantity: Tandem

Suspension: Spring

Axle Capacity: 3500 lb.

GVWR: 7000 lb.

Flooring 3/4" High Performance Engineered

Side Door

PT Door with Flush Lock / Dead Bolt

Width: 32"  - Height: 72"

Rear Opening

Ramp Door with Bar Lock

Width: 75" - Height: 76"

Frame Construction 2" x 6" Tube

Tie Downs 3 -  1000lb Recessed Floor Mounted Tie-Downs

Warranty 3-Year Limited Warranty

Customization Available? Yes

Truck'n America strives to ensure the accuracy of information presented on this site. However there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.

Tires:  ST205/75R15 C rated

Features:

• 24" visqueen corrosion liner - Moisture protection in inner wall to minimize corrosion

• Front and rear ramp doors - Easy drive-in, drive-out access

• Spring assist rear ramp door - Easily lower and raise ramp door

• Rust inhibiting chassis protection - Longer trailer life

• 3/4" high performance engineered floor & ramp decking - Treated to resist damage from melting snow

• 1000 lb. recessed floor mounted tie-downs - Prevents ATVs or snowmobiles from moving during transit

• 12" kick plate along sidewalls - Protects trailer from damage when loading

• 16" high performance engineered ramp extension  - Smoother loading and unloading

Truck'n America strives to ensure the accuracy of information presented on this site. However there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.
